Slider-crank mechanism of the steam engine

Muse­ums and archives

Mech­a­nism is stored in the Musée des arts et métiers du Con­ser­va­toire national des arts et métiers (Paris, France); CNAM № 12441-0000.


Research

I. I. Arto­bolevsky, N. I. Lev­it­sky. Tcheby­shev's Mech­a­nisms / In: P. L. Tcheby­shev’s Sci­en­tific Her­itage. Iss. 2. The­ory of mech­a­nisms. — Moscow-Leningrad: AS USSR. 1945. P. 69–70. (Russ­ian)

I. I. Arto­bolevsky, N. I. Lev­it­sky. Mod­els of mech­a­nisms of P. L. Tcheby­shev / In: The com­plete works of P. L. Tcheby­shev. Vol. IV. The­ory of mech­a­nisms. — Moscow-Leningrad: AS USSR. 1948. P. 230–232. (Russ­ian)


Other sources

Let­ter of the 2th June 1893 from the direc­tor of the Con­ser­va­toire National des Arts et Métiers (National Con­ser­va­tory of Arts and Crafts) to P. L. Tcheby­shev (about the sec­ond model of the arith­mome­ter and the dona­tion of the model of slider-crank mech­a­nism of the steam engine; In French; Archive of the RAS, fonds 505, opis 1, № 107).

A few words about new inven­tions of aca­d­e­mi­cian P. L. Tcheby­shev // Zapiski of the Moscow Branch of the Impe­r­ial Russ­ian Tech­ni­cal Soci­ety. 1893. Iss. 1 и 2. (Russ­ian)


All Mechanisms

Reconstruction
Reconstruction
Model by Tchebyshev (CNAM)
Model by Tchebyshev (CNAM)
Model label (CNAM)
Draft model (reproduction)
